Stainless steel 304 strip
ASTM A240 TP 304 Cold Rolled Strips Manufacturer in India
Table of content
- Stainless steel 304 Strip Specification
- AISI 304 Flat Strip Chemical Composition
- Mechanical Properties of ASME SA 240 Grade 304 Precision Strip
- Din 1.4301 Hot Rolled Strips Equivalent Grades
- Physical Properties of SUS S30400 Flat Strip
- Stainless steel 304 Strip Price List
- Features of 304 Stainless Steel Brushed Strip
- ASTM A240 TP 304 Cold Rolled Strips Width Tolerance
- UNS S30400 Polished Strip Testings
- Applications of SA 240 SS 304 Hot Rolled Strips
ASTM A240 Type 304 cold rolled strips have width of upto 600mm, Check price list of 304 Stainless Steel brushed strip
Stainless steel 304 Strip Specification
| ASME SA 240 Type 304 Cold Rolled Strips Thickness | SUS 304 Polished Strip Width | AISI 304 Precision Strip Length |
|---|---|---|
|
|
|
| DIN 1.4301 Thin Strip Finishes | A240 gr 304 Flat Strip Manfacturing Process | SA 240 Grade 304 Brushed Strip Advantages |
|
|
|
| ASTM A240 TP 304 Strip Packages | SS 1.4301 Hot Rolled Strips Export to | SA 240 SS 304 Polished Strip Uses |
|
|
|
| 304 Stainless Steel Thin Strip Standard | ASME SA 240 Grade 304 Flat Strip Specifications | 304 SS Hot Rolled Strips Temperature |
|
|
|
| Stainless steel 304 Strip Form | INOX 304 Precision Strip Hardness | Alloy 304 SS Cold Rolled StripsProfiling |
|
|
|
Manufacturer of AISI 304 polished strip in Full Hard condition, ASTM A240 TP 304 precision Strip have high ductility and forming properties
AISI 304 Flat Strip Chemical Composition
| Grade | C | Si | Mn | S | P | Ni | Cr | N |
|---|---|---|---|---|---|---|---|---|
| 304 | 0.03max | 0.75max | 2.0max | 0.03max | 0.45max | min: 8.0 max: 12.0 | min: 18.0 max: 20.0 | 0.10 max |
Mechanical Properties of ASME SA 240 Grade 304 Precision Strip
| Grade | Yield Strength 0.2% ksi (min) | Tensile Strength ksi (min) | Elongation % | Hardness MAX (Rockwell B) | Hardness MAX (Brinell) |
|---|---|---|---|---|---|
| 304 | 25 | 70 | 40 | 92 | 201 |
Din 1.4301 Hot Rolled Strips Equivalent Grades
| STANDARD | UNS | WERKSTOFF NR. | JIS | BS | AFNOR | EN | GOST |
|---|---|---|---|---|---|---|---|
| SS 304 | S30400 | 1.4301 | SUS 304 | 304S31 | Z7CN18‐09 | X5CrNi18-10 | 08Х18Н10 |
Physical Properties of SUS S30400 Flat Strip
| Density lbm/in3 |
Melting Range °F |
Thermal Conductivity BTU/h ft. °F |
Modulus of Elasticity (psi x 106 |
Electrical Resistivity in x 10-6 |
Specific Heat | Coefficient of Thermal Expansion: (in/in)/ °F x 10-6 |
|---|---|---|---|---|---|---|
| 12.4 at 932 °F | 39.4 at 752°F | 10.2 at 32 – 1000°F | ||||
| at 68°F: 0.285 | 2500 to 2590 | 9.4 at 212°F | 28 | 28.3 at 68°F | 0.1200 at 68°F to 212°F | 9.4 at 32 – 212°F |
| 10.4 at 32 – 1500°F | 49.6 at 1652 °F |
Stainless steel 304 Strip Price List
| Product | Price in US $ | Price In UAE |
|---|---|---|
| Stainless Steel 304 Strip 1 mm | $ 2.20 | UAE 8.08 |
| UNS S30400 SS Strip 3mm | $ 2.32 | UAE 8.52 |
| ASTM A240 SS Strip 1mm | $ 2.50 | UAE 9.18 |
Chromium in SUS 304 strip increases its corrosion resistance property, Alloy 304 thin strip are available in various finishes
Features of 304 Stainless Steel Brushed Strip
- Strength
- Corrosion Resistance
- Temperature Resistance
- Durability
- Low Maintenance
- Aesthetic Appeal
- Non-Magnetic
- Ductility
DIN 1.4301 hot rolled strips can be used in corrosive condition, View dimension and tolerance of UNS S30400 flat strip
ASTM A240 TP 304 Cold Rolled Strips Width Tolerance
| Nominal length | Tolerances | |||
|---|---|---|---|---|
| Mill edges | Trimmed edges1) | |||
| Upper | Lower | Upper | Lower | |
| > 1500 | + 20 | 0 | +6 | 0 |
| > 1200 < 1500 | + 20 | 0 | + 5 | 0 |
| < 1200 | + 20 | 0 | + 3 | 0 |
UNS S30400 Polished Strip Testings
- Hardness Test
- Intergranular Corrosion (IGC) Test
- Dye Penetrant Test (DP Test)
- Hydrostatic Test
- Eddy Current Testing
- Pitting Resistance Test
- Micro Test, Macro Test
- Positive Material Identification – PMI Testing
- Chemical Analysis – Spectro Analysis
- Flaring Test, Flattening Test
- Radiography Test
- Impact Test
- Ultra Sonic Test (UT)
Applications of SA 240 SS 304 Hot Rolled Strips
- Cookware
- Food service Equipment
- Stamped Machined Products
- Kitchen
- Railway Cars
- Appliances
- Sinks
- Tractor
- Automotive Trim
- Trailers
